Marks Metro Mortise Lockset 114 Series

Keep the entry doors on your commercial or residential property secure with the Marks USA Brass Entry Knob with Double Cylinder Deadbolt. The lock features a brass finish for durability, and a double cylinder deadbolt offers excellent security for your entry door.

Specifications

• Thru-bolted knob/plate assemblies integrate and align with lock body.
• Standard Finish: US 3
• Exterior: Wrought brass, screwless round knob, 2-1/4" diameter on steel reinforced brass plate, 10" x 2-3/4". Two thru posts pass thru lock body. Integral spring-loaded 9/32" spindle.
• Interior: Wrought brass, screwless round knob, 2-1/4" diameter on steel reinforced brass plate, 7" x 2-1/4". Exposed 8-32 mounting. Bolts engage outside plate assembly. Integral spring- loaded 9/32" spindle.
• Cylinder: 5-pin cylinder, 1-1/8" long
• Strike: Conforms to ANSI spec.A115.1, 4-7/8" x 1-1/4" x 3/32" thick, 5/8" curved lip
• Door Thickness: 1-1/4" to 1-3/4"
• Backset: 2-1/2"
• Lock Front: 7-5/8" x 1-1/16", .187" thick, flat or 3° bevel, solid brass. Optional front: 8" x 1-1/4" steel backplate with brass cover plate.
• Deadbolt: Cast brass, 1" throw
• Latch: Solid brass, 1/2" throw, reversible
• Rocker Switch: Locks or unlocks hub
• Hubs: 9/32" on square with steel security separator
• Hub Lock Arm: Steel, .125" thick
• Case: High pressure cast Zamac, baked enamel finish
